亮点：
Highlights:
1、采用双机油缸，配有大体积胶缸，可一次性装载14L丁基胶（2块正常的￠180mm的丁基胶）。
1. Double machine oil cylinder is adopted and equipped with large volume rubber cylinder, which can load 14L butyl rubber (two normal ￠ 180mm butyl rubber) at one time.
2、增压系统的主泵采用德国原装进口麦格思维特（MAXIMATOK）的增压泵。
2. The main pump of the booster system adopts the booster pump of maximatok imported from Germany.
主要性能特点:
Main performance features:
1、该机为半自动涂布机（即人工扶持间隔框进行逐边操作）,变频调速。
1. The machine is a semi-automatic coater (i.e. manually supporting the spacer to operate side by side), with variable frequency speed regulation.
2、将间隔框放在传送带上人工扶持框传送带运行，通过传感器时，传送压轮及打胶阀按设定程序自动动作。
2. Place the spacer frame on the conveyor belt and manually support the conveyor belt to run. When passing through the sensor, the transmission pressure wheel and glue valve will act automatically according to the set program.

3、摆动气缸动作、压轮压下，压送铝间隔框行进，当间隔框到达打胶头时打胶，将胶均匀地涂在铝间隔框上。
3. Swing the air cylinder and press down the pressure wheel to press the aluminum spacer frame. When the spacer frame reaches the gluing head, apply the glue evenly on the aluminum spacer frame.
4、等间隔框另一侧快要到达压轮时，压轮抬起，离开打胶头时，胶阀自动关闭，停止打胶，以上程序由PC控制，时间有人机界面控制，可以触摸调节。
4. When the other side of the equal interval frame is about to reach the pressing wheel, the pressing wheel will lift up. When leaving the gluing head, the glue valve will automatically close and stop gluing. The above program is controlled by PC, and the time is controlled by man-machine interface, which can be adjusted by touch.
5、在设计、选用元气件以及涂胶效果方面，在国内均属水平。
5. In terms of design, selection of vitality parts and gluing effect, it is at the domestic level.
6、采用PC控制系统，定位、传送、涂胶均自动完成。
6. Using PC control system, positioning, transmission and gluing are completed automatically.
7、输送采用变频调速电机调速，运行速度平稳。
7. The transmission adopts frequency conversion speed regulation motor speed regulation, and the running speed is stable.
8、有不泄压即可自动调定位机构，充分保证涂胶胶头与隔框两侧间距涂胶均匀。
8. The positioning mechanism can be adjusted automatically without pressure relief to fully ensure the uniform spacing between the gluing head and both sides of the spacer frame.
以上就是为大家介绍的有关全自动丁基胶涂布机的详细介绍,希望对您有所帮助.如果您有什么疑问的话,欢迎体育竞技领航者.我们将以的态度,为您提供服务http://www.holycitylaw.com
The above is a detailed introduction to the full-automatic butyl adhesive coater. I hope it will be helpful to you If you have any questions, please contact us We will provide you with professional service http://www.holycitylaw.com
